产品名称：网络测试仪 UPY-2002A 思博伦 SPIRENT POS/ATM
产品型号：UPY-2002A
生产厂商：spirent
产品数量：100
产品单价：100000.00RMB
详细介绍

SPIRENT POS/ATM


SPIRENT POS/ATM UPY-2002A

网络测试仪 UPY-2002A 思博伦 SPIRENT POS/ATM



Environment/Versions

  • The November 2019, 5.04 release is the last version with support the following equipment

    • Release 5.05 and above has no firmware or software for this equipment.

    • Cards inserted into N4U, N11U an N12U show obsolete


  • For hardware discontinued in later versions, see FAQ19360

Answer

  • This is the list of equipment no longer supported as it is obsolete

    • Chassis

      • SPT-2u

      • SPT-3u

      • SPT-9u

      • SPT-11u


    • Cards


CM-10G-S2 Hypermetrics CM 10GBE SFP+ 2-Ports
CM-1G-D12 Hypermetrics CM 10/100/1000 Dual Media 12-Ports
CM-1G-D4 Hypermetrics CM 10/100/1000 Dual Media 4-Ports
CPR-1001A Series 1000: 8 Port 10/100 Copper RJ45 Test Module
CPR-1001B Series 1000: 8 Port 10/100 Copper RJ45 Test Module
CPR-2001A Series 2000: 8 Port 10/100 Copper RJ45 Test Module
CPR-2001B Series 2000: 8 Port 10/100 Copper RJ45 Test Module
CPR-2002A Series 2000: 8 Port 10/100 Copper RJ45 Test Module
CPR-2002B Series 2000: 8 Port 10/100 Copper RJ45 Test Module
CV-10G-S2 Hypermetrics CV 10GBE SFP+ 2-Ports
CV-10G-S8 Hypermetrics CV 10GBE SFP+ 8-Ports
CV-8GFC-S2 Hypermetrics CV 2/4/8G Fibre Channel SFP+ 2-Port
DX-10G-S32 Hypermetrics DX 10GBE SFP+ 32 Ports
EDM-1001A Series 1000: 4 Port 1G Dual Media Test Module
EDM-1001B Series 1000: 4 Port 1G Dual Media Test Module
EDM-1002A 1000 Series - 10/100/1000 Dual Media, 2 Port
EDM-1002B 1000 Series - 10/100/1000 Dual Media, 2 Port
EDM-1003A 1000 Series - 10/100/1000 Dual Media, 12 Port
EDM-1003B 1000 Series - 10/100/1000 Dual Media, 12 Port
EDM-2001A Series 2000: 4 Port 1G Dual Media Test Module
EDM-2001B Series 2000: 4 Port 1G Dual Media Test Module
EDM-2002A 2000 Series - 10/100/1000 Dual Media, 2 Port
EDM-2002B 2000 Series - 10/100/1000 Dual Media, 2 Port
EDM-2003A 2000 Series - 10/100/1000 Dual Media 12 Port
EDM-2003B 2000 Series - 10/100/1000 Dual Media, 12 Port
FBR-1001A Series 1000: 8 Port 10/100 Fiber SFP Test Module
FBR-1001B Series 1000: 8 Port 10/100 Fiber SFP Test Module
FBR-2001A Series 2000: 8 Port 10/100 Fiber SFP Test Module
FBR-2001B Series 2000: 8 Port 10/100 Fiber SFP Test Module
MSA-1001A 1000 Series - 10GBE Multiple-MSA Host Module, 2- Ports
MSA-1001B 1000 Series - 10GBE Multiple -MSA Host Module, 2- Ports
MSA-2001A 2000 Series - 10GBE Multiple -MSA Host Module, 2- Ports
MSA-2001B 2000 Series - 10GBE Multiple -MSA Host Module, 2- Ports
UPY-2001A 2000 Series - 10G Host Module, 1- Port
UPY-2002A 2000 Series - Host Module, 2- Ports
WAN-2002A 2000 Series - 2.5G WAN Host Module, 2- Ports
WAN-2003A 2000 Series 2 PORT 622 MB/S Host Module
XFP-1001A Series 1000: 1 Port 10G XFP Test Module
XFP-1001B Series 1000: 1 Port 10G XFP Test Module
XFP-2001A Series 2000: 1 Port 10G XFP Test Module
XFP-2001B Series 2000: 1 Port 10G XFP Test Module




IXIA OPTIXIA LSM10GXM8S-01 10 GIGABIT ETHERNET LOAD MODULE

Ixia Optixia LSM10GXM8S-01 10 Gigabit Ethernet Load Module

  • 8-Port LAN/WAN, SFP+ interface with 1GB RAM per port.

  • 10 Gigabit Ethernet Load Module is compatible with the XGS12-SD 12-slot, standard performance rack mount chassis bundle (940-0011), XGS12-HS 12-slot, high-speed performance rackmount chassis bundle (940-0006), XG12 12-slot, rackmount chassis (940-0005), XGS2-SD 2-slot, 3RU standard performance chassis bundle (940-0010), XGS2-HS 2-slot, 3RU high-speed performance chassis bundle (940-0012) and the XM2 desktop chassis (941-0023)

  • Full L2/7 support; REQUIRES one or more SFP+ transceiver options: 948-0013 10GBASE-SR, 948-0014 SFP+10GBASE-LR, 948-0015 SFP+10GBASE-LRM, or 948-0016 SFP+10GSFP+Cu

The NGY series of load modules delivers higher control plane performance and scalability for both 3 routing protocol emulation and upper 4-7 stateful traffic testing in both the full performance SFP+ (LSM10GXM8S) and 10GBASE-T (LSM10GXM8GBT) The NGY series of modules is a high-density 10 Gigabit Ethernet test solution, with up to 96 ports of 10GE test ports in a single XGS12-SD Standard Performance or XGS12-HS High Performance chassis. Ixia’s high density 10 Gigabit Ethernet load modules are available with a reduced performance option. The reduced performance option provides limited 3 routing emulation and control planeperformance, coupled with complete 2 and 3 data plane testing. When physical port scalability and efficient use of lab facilities are critical, the LSM10GXMR8, MR4, and the highly economical MR2 reduced feature load modules are the most affordable 10GbE test solution available for manufacturing and large port count test beds. A broad portfolio of enterprise, data center Ethernet, storage area networks, metropolitan-edge, and core network test solutions are supported, including performance, scalability, and conformance testing of 2-3 devices. Data and control planes may be simultaneously tested, including routing protocols and stateful testing of 4-7 content-aware devices and networks.

  • 96 ports per 12-slot chassis

  • Reduced rack space ? Reduced power consumption, and cooling requirements

  • Up to 50% less power consumption than the nearest competitor – less lab cooling required

  • Tracks and analyzes up to 1 million flows per port for real-time latency, Inter-arrival time, packet loss, data integrity, sequence checking

  • Comprehensive Layer 2-7 testing ? Integrated data plane and control plane traffic generation and analysis

  • Layer 2/3 data plane testing

  • IPv4/v6 routing protocol emulation

  • Bridging protocols: FCoE, 802.1Qbb, MPLS VPNs, MPLS-TP, Multicast 1588v2, Sync-E ? Stateful Application Layer 4-7 testing

  • Sophisticated multi-protocol encapsulation and label stacking

回收置换：台湾拓码NuStreams机架式产品

台湾拓码NuStreams机架式产品

  Chassis测试机箱：

  NuStreams-700 Chassis

  NuStreams-2000i Chassis

  NuStreams-600i Chassis

  Module测试板卡：

  10G Module：SFP+，XM-RM881，XM-RM881-2，XM-RM891,XM-RM882,XM-RM882-2

  1G Module:SFP,RJ45,XM-RM781,XM-RM761,XM-RM751,XM-RM731

  100M Modu1le:SFP,RJ45,XM-RM661,XM-RM681

  Software软件：

  APMPT-4，APMPT-3，NuApps-2544-RM，NuApps-2889-RM

北京信而泰XINERTEL，Teltest

  机箱BigTao210，BigTao6100,Bigtao220,BigTao-6200,BigTao200,BigTao-6000，iTester，DarYu-X，DarYu3000，DarYu120000，Xcompass-S

  测试板卡，P2-10G，P6000，P8000，P8000，P9000，V6000，V8000，P6016C，P6012F，P6016E，P6012C，P8008F，P8004F，P8002C,P8008M，P2-100G，V6016C,V6016M,V6012C,V6008F,V6004C，V8008F,V2-10G，V2-100G，V2-100G-4QSFP28-Q，V2-10G-8C-Q， X1-10G-16F-Q，X1-100G-4QSFP28-HQ，X1-100G-12QSFP28-Q

  软件：Renix，TeleATT

是德IXIA

  Ixia机框：XM12,XM2，Ixia400T，XGS2 Chassis Platform，XGS12，IXIA1600T,IXIA400T，Optixia X16，IxN2X，WaveTest WLAN，AresONE，

  测试板卡：LSM10GXM8S-01,LSM10GXMR2-01,LSM1000XMV,LSM1000XMVR16,LAVA AP40G/100GE 2P,

  软件：IxLoadp评估多重播放业务和应用系统的系统，IxNetwork-2-3层性能测试软件，IxAutomate自动化测试套件，IxChariot系统性能分析软件，IxDefend网络设备健壮性评估工具，IxANVL协议一致性测试软件包

思博伦Spirent

  机箱：Spirent SPT N4U，SPT-N11U，SPT N12U, Testcenter C1，Smartbits，Testcenter C100，SPT-N4U，SPT-N11U,SPT-2U，SMB600B，，SPT-3U，SMB600B

  板卡，SMB LAN-3101B,SMB LAN-3324A，LAN-3325A,LAN-3321A,LAN-3320A,XLW-3720A,

  其他，Testcenter Appliance，C1，C50，C100，C50-100G

  Testcenter Module，DX3，PX3，FX2，MX3系列，FX-100G-F2,DX-10G-S32,FX2-1G-S12,CV-10G-S2,DX2-100GO-P2，DX2-40GO-Q8， FX2-10G-Q5，EDM-1003B,EDM-2003B,，FX2-10G-S8,CM-1G-D12,CV-10G-S2,ANUE CKL-2U
