Anritsu 安立 MG9638A可调光源 TUNABLE LASER SOURCE

MG9637A用於评估为 WDM (特别是 DWDM) 传送之光纤放大器的波长特性。有高度稳定的输出及光源。适合测试光学配件之波长i稳定性。
·MG9637A可调激光信号源
·单模输出；
·1 pm波长设置精度；
·*大±7 pm可重复性波长；
·+4 dBm或更大输出电平；
·两个输出端口。

Used to evaluate the wavelength characteristics of optical fiber amplifiers used in WDM (especially DWDM) transmission from 1500 to 1580nm. It uses a semiconductor amplifier providing a high-power output of at least +4 dBm.

Features:

• Single moded emission 1500 to 1580nm
• 1 picometer wavelength setting resolution
• Within 7 picometer wavelength repeatability
• Within 4 dBm or more output
• Two output ports
